- 6th Generation Intel® Core™ i7/ i5/ i3 U-series SoC (Skylake-U)
- DDR4 2133MHz memory, up to 16GB
- Onboard DVI-D and DisplayPort display interfaces support up to 4K resolution
- Up to 5 Independent GigE LAN, iAMT 11.0 supported
- Optional supports full function SUMIT A, B expansions
- Fanless, -40°C to 85°C Operating Temperature
- 9V to 36V DC Power Input
- 16 Isolated DIO
- 4 USB 3.0, 9 COM RS-232/ 422/ 485
- One-stop SUMIT Expansion Design and Manufacturing Services
Intel® Core™ i7/ i5/ i3 U-series Processor (Skylake-U) Ultra-compact Fanless Embedded Box PC, 4 GigE LAN, 2 SSD, 1 SIM, 4 USB 3.0, 9 COM, 16 Isolated DIO, -40°C to 85°C, Rugged, High Performance, Extended Temperature
Model | LAN | SSD Tray | USB | COM | SIM | Isoloated DIO |
|---|---|---|---|---|---|---|
SPC-3510-600U | 2 | 1 | 4 | 2 | 1 | NA |
SPC-3510-300U | 2 | 1 | 4 | 2 | 1 | NA |
SPC-3510-100U | 2 | 1 | 4 | 2 | 1 | NA |
SPC-3510-955U | 2 | 1 | 4 | 2 | 1 | NA |
SPC-3520-600U | 4 | 1 | 4 | 5 | 1 | 16 |
SPC-3520-300U | 4 | 1 | 4 | 5 | 1 | 16 |
SPC-3520-100U | 4 | 1 | 4 | 5 | 1 | 16 |
SPC-3520-955U | 4 | 1 | 4 | 5 | 1 | 16 |
SPC-3530-600U | 4 | 2 | 4 | 9 | 1 | 16 |
| System | |
| Processor |
Intel® Core™ i7/i5/i3/Celeron® U-series Processor (Skylake-U)
|
| Chipset | Intel® SoC (Skylake) |
| BIOS | AMI |
| SIO | IT8786E |
| Memory | 1 DDR4 2133/ 1866 MHz SO-DIMM, up to 16GB |
| I/O Interface | |
| Serial | Up to 9 COM RS-232/ 422/ 485 |
| USB |
- 4 USB 3.0 (External)
- Up to 4 USB 2.0 (Internal) |
| DIO |
SPC-3520, 3530 : 16 Isolated DIO : 8 DI, 8 DO
SPC-3510 : 16 GPIO (Internal)
|
| LED | Power, HDD |
| SIM Card | 1 SIM Card Socket (Internal) |
| Expansion | |
| Mini PCIe |
2 Mini PCIe Socket :
- 1 Full-size PCIe/USB/Internal SIM Card
- 1 Full-size for PCIe/USB/mSATA
|
| SUMIT A, B | 2 SUMIT Slot (Optional) |
| Graphics | |
| Graphics Processor | Intel® HD Graphics 520 |
| Interface |
- DVI-D : Up to 1920 x 1080 @ 60Hz
- DisplayPort : Up to 3840 x 2160 @ 60Hz
|
| Storage | |
| SATA | 2 SATA III (6Gbps) support S/W RAID function |
| mSATA | 1 SATA III (Mini PCIe Type, 6Gbps) |
| Storage Device |
2 2.5" SSD/HDD Bracket (Internal)
|
| Audio | |
| Audio Codec | Realtek ALC892, 5.1 Channel HD Audio |
| Audio Interface | 1 Mic-in, 1 Line-out |
| Ethernet | |
| LAN 1 | Intel® I219 Gigabit LAN supports iAMT 11.0 |
| LAN 2 | Intel® I210 Gigabit LAN |
| LAN 3 | Intel® I210 Gigabit LAN |
| LAN 4 | Intel® I210 Gigabit LAN |
| LAN 5 | Optional by SUMIT expansion |
| Power | |
| Power Input | 9V to 36V, DC-in |
| Power Interface | 3-pin Terminal Block : V+, V-, Frame Ground |
| Remote Switch | 2-pin Terminal Block |
| Others | |
| Watchdog Timer | Reset : 1 to 255 sec./min. per step |
| Smart Management | Wake on LAN, PXE supported |
| HW Monitor | Monitoring temperature, voltages. Auto throttling control when CPU overheats. |
| Software Support | |
| OS | Windows 10, Windows 8.1, Windows 7, Linux |
| Mechanical | |
| Dimension (W x L x H) |
SPC-3510 : 150mm x 106mm x 62mm (5.9”x4.2”x2.5”)
SPC-3520 : 150mm x 106mm x 86mm (5.9”x4.2”x3.4”)
SPC-3530 : 150mm x 106mm x 100mm (5.9”x4.2”x3.9”)
|
| Weight |
SPC-3510 : 1.4 kg (3.08 lb)
SPC-3520 : 1.8 kg (3.97 lb)
SPC-3530 : 2.1 kg (4.62 lb)
|
| Mounting |
- Wallmount by mounting bracket
- 2U Rackmount (Optional)
|
| Environment | |
| Operating Temperature | -40°C to 85°C (-40°F to 185°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% Humidity, non-condensing |
| Relative Humidity | 95% at 70°C |
| Shock |
- IEC 60068-2-27
- SSD : 50G @ wallmount, Half-sine, 11ms
|
| Vibration |
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
|
| EMC | CE, FCC, EN50155, EN50121-3-2 |
| Attachment | Size |
|---|---|
 SPC 3500 Series Data Sheet | 1.57 MB |
